MAN TGM 18.250 BB CH 4x4 Crane Truck

2 units in stock

€ 135.000

Net unit price, EXW Nieuwerkerk aan den IJssel (NL), without VAT, subject to availability/prior sale.

  • Stock number VMA5258
  • Superstructure Crane Truck
  • Construction make Fassi
  • Axle configuration 4x4
  • Engine power 250hp/184kW
  • Emission EURO-4
  • Fuel Diesel
  • Engine type D0836LFL95
  • Cylinder capacity 6.871 cc
  • Cylinders 6
  • Transmission Automatic
  • Gearbox TipMatic 12.12OD
  • Suspension Spring
  • Tyres 14.00R20
  • Wheelbase 4.500 mm
  • Cabin Day
  • Total weight GVW 18.000 kg
  • Model year 2023
  • Production year 2023
  • Remarks Fuel tank: 300 ltr.
    Air conditioning

    Equipped with Fassi crane and flatbed:
    Type: F155A.0.22
    Lifting moment: 133 KNm.
    Standard hydraulic reach: 8.30 mtr.
    Load at the max horizontal outreach: 1660 kg.
    Hydraulically extra extendable outriggers
    Long fixing rods

    Lifting capacity:
    6.160 kg / 2.15 m
    3.150 kg / 4.30 m
    2.190 kg / 6.10 m
    1.660 kg / 8.00 m

    Open flatbed body with foldable sideboards.

    Complete specification in PDF.
